Fernco Coupling 98-115
Product No.: 192545010 Product No.: 192545010 DB No.: 5829154Login
The flexible Fernco coupling ensures leak-proof pipe seals on almost any pipe material: plastic, cast iron, asbestos cement, clay, concrete, steel, copper and ductile iron. This coupling is used on sewage and drainage pipe in soil. The coupling resists constant temperatures from -34 to +40°C. It can briefly resist temperatures up to 60°C (2-3 minutes).
- Fernco Coupling 98-115
- Thermoplast / Acid resistant stainless steel (AISI 316)
- Pipe diameter A: 98-115 mm
- Pipe diameter B: 98-115 mm
- Width/thickness: 100 mm / -
- Chemical resistance: -
- Constant thermal resistance: -34 to +40°C
- Brief thermal resistance: +60°C (2-3 minutes)
- Clamping system: Acid resistant stainless steel (2) - 8 mm top (2)
- Torque: 12 Nm
Show more +
Show less −
Product information
Fernco coupling
Fernco coupling are used worldwide and have earned a reputation for consistent, superior performance, giving you full confidence in their quality and reliability. The dimensional flexibility of Fernco couplings ensures leak-proof pipe seals on virtually any pipe material: plastic, cast iron, asbestos cement, clay, concrete, steel, copper and ductile iron. Furthermore, the coupling are very resistant to chemicals, UV radiation and other normal occuring sewer gases.
Advantages
- Tested designs backed by over five decades of proven performance
- Positive seal against infiltration and exfiltration
- Leak-proof and is resistant to chemicals, ultraviolet rays, fungus growth, and normal sewer gases
- Conforms to ASTM D 5926, C 1173 and CSA B602
- Connects same or different pipe sizes and materials quickly and easily
- Stainless steel clamps are corrosion-resistant and rustproof
Product specs
- EAN/GLN No.:
- 5711340001538
- DB No.:
- 5829154
- Product No.:
- 192545010
- Customs Tariff No.:
- 39174000
- Specification:
- 110 plast - 110 plast
- Max.:
- 2000
- Unit:
- Pcs
- Weight in kg:
- 0,59
- Number per box:
- 35
- Number per pallet:
- 400
- Dimension Minimum (mm) 1:
- 98
- Dimension Maximum (mm) 1:
- 115
- Dimension Minimum (mm) 2:
- 98
- Dimension Maximum (mm) 2:
- 115
- Material:
- PVC
- Pipe material from:
- 110 plastic
- Pipe material to:
- 110 plastic
- Thermal resistance (˚C) from::
- -34
- Thermal resistance (˚C) to::
- 40
- Call for a price:
- Yes
Show more +
Show less −
Documents/Video
| Name | Type | Size |
|---|---|---|
VA_2.23_19494_Fernco.pdf
|
636 KB | |
|
Fleksible_overgange_fernco_100160.pdf
|
4543 KB | |
|
vejledning_fleksibel_overgang_overgangsmanchetter_12nm.pdf
|
230 KB | |
| Video | - |
